Volsun VS-SCGT Series High-temperature Resistant Ceramic Insulation Tape
Time: 2025-05-23 15:03:43     Copyfrom: SuZhou Volsun Electronics Technology Co.,Ltd.

In electric vehicles, energy storage systems, and other high-temperature industrial fields, the safe operation of electrical equipment faces great challenges. High temperature, flames, chemical corrosion and other factors constantly threaten the stability and service life of the equipment. Volsun's VS-SCGT high-temperature insulation tape has become a reliable choice for ensuring the safety of electrical equipment with the following several excellent performance.

1. High temperature resistance and ablation resistance:

This kind of tape is mainly made of ceramic silicone rubber and fire-resistant reinforcing fiber, which can resist 1000℃ flame ablation. It can quickly form a ceramic structure at high temperature, effectively preventing the spread of flames and protecting the safety of equipment.

2. Excellent insulation:

The high-temperature insulation resistance of this tape is ≥1.0×10⁵Ω at 800℃ and 1min, the dielectric strength is ≥20kV/mm, and the volume resistivity is ≥1.0×10¹²(Ω・cm). Even in high temperature environments, it can provide reliable insulation protection to prevent leakage accidents.

3. Chemical corrosion resistance:

It can effectively isolate most chemical solvents, and can still maintain stable performance in complex chemical environments to ensure the protective effect of the tape.

4. Environmental protection and safety:

This high temperature resistant insulation tape complies with RoHS environmental protection standards, has low smoke, low flame, and no smoke toxicity during combustion, and has excellent ozone and UV aging resistance, making it safe to use.

In addition, Volsun's high-temperature insulation tape has a variety of specifications to choose from, with thickness ranging from 0.25mm to 0.90mm, a fixed width of 25±1.0mm, and a packaging length of 50m/roll. It is mainly used in electric vehicle battery packs, energy storage systems, and other industrial equipment with high requirements for heat resistance and insulation. In electric vehicles, it can enhance the safety of battery packs; in energy storage systems, it can ensure stable operation of equipment and reduce the risk of failure.

Welcome to contact us to learn more about high-temperature protection solutions!
