Aramid 1414 lashing rope
- Detailed
Description
It is composed of poly(p-phenylene terephthalamide) fiber which is light，smooth surface, strong and tough mechanical properties, excellent high temperature resistance, corrosion resistance and excellent dielectric properties. It is used in high-performance structural parts of aviation, aerospace, high-speed trains and automobiles, rail transit, nuclear power, hydropower and power grid engineering, high-end insulation materials for large motors and transformers.
Feature
l Temperature Resistance Grade: C
l Color: Light yellow
l Operating Temperature: : -70℃～+200℃
l Light, high strength, excellent aging resistance
l No decompose and melt at high temperature. Alkali corrosion resistance, high temperature resistance
Technical Performance
|
Item |
Technical Performance |
Test Standard |
|
Appearance |
No burr, No yarn fall off |
Visual |
|
Oxygen Index |
30% |
GB/T 5454 |
|
Tear Strength |
≥800N（Diameter1.3mm） |
GB/T 8834-2016 |
|
Elongation at break |
≤10% |
GB/T 8834-2016 |
|
High temperature resistance |
No melting and no coking by visual inspection |
FZ/T 63045-2018 （204±5℃，5min） |
Structure
Structure
Dimension
|
Diameter（mm） |
Tolerance（mm） |
Package length（m） |
|
0.9 |
0.9±0.1 |
500 |
|
1.3 |
1.3±0.15 |
500 |
|
1.5 |
1.5±0.2 |
500 |
|
1.8 |
1.8±0.2 |
500 |
NotNote: Special sizes and package are available as request.
